Overview Technical Specifications Differentials and Optional

Advanced design and manufacturing processes are used.
It has stable structure and reliable performance.
It can ensure the safety and stability of the operation.
The bed surface is made of high quality material, with good wear resistance and easy cleaning, which can meet clinical hygiene requirements; The reasonable design of the bed surface can reduce the inconvenience and fatigue during the operation, improve the work efficiency and the quality of the operation.
With a variety of adjustment functions, the height, Angle and position can be adjusted according to the needs of surgery, providing a comfortable surgical environment and operating space.
The bed surface is flat and adjustable, which can meet the needs of different surgical operations, improve the operating efficiency of doctors and the comfort of patients.
It is equipped with a variety of auxiliary facilities, such as shoulder support, waist support and leg support, so as to facilitate the operation of medical staff.

Table length	Table width	Table lift adjustment range
≥2070mm	≥520mm	540m-1040mm
Action items	Type:TP3000-H
Adjust angle of the backplane	Up	≥80°
	Down	≥40°
Adjust angle of lateral tilt	≥30°
Adjust angle of vertical tilt	≥20°
Angle of head board	Up	≥15°
	Down	≥90°
Angle of leg board	Up	≥15°
	Down	≥90°
Load capacity	≥250kg

Surgical sheet configuration

Head board     1pc
Hand board    2pcs
Leg board    2pcs
Mattress    1set
Fabric curtain holde    1pc
Hand controls    1set

Optional：
Orthopedic traction frame, the main structure is made of high-quality stainless steel, suspension design, and equipped with accessories trolley
Carbon fiber orthopedic traction frame can also be selected, the main structure is made of carbon fiber material, can be X-ray, easy to use
