Overview Technical Specifications Differentials and Optional

Features

This product is suitable for the examination room and treatment room to illuminate the patient's body.It is widely used in clinices, gynecology, medical cosmetics surgery and other fields.

One-button operation control, easy to adjust the lighting mode and lighting intensity，Stepless adjustment
Ultra-high transmittance optical lens with excellent lighting quality
13W low power, high light efficiency OSRAM imported LED chip
50000h long service life of the lighting source, each LED can be replaced separately, to ensure the maximum economy of use
The disinfecting handle can be easily removed to facilitate disinfection and cleaning
Small portable, and any angle can be bending. floor type, strong heat dissipation, low power consumption
Cold light lamp beads, uniform illumination, pure white light source. Stainless steel telescopic pole, adjust the height of the light pole at will
Flexible hose, multi-angle lighting,  stable work, beautiful appearance

Items	S100	S280/S300
Diameter of light head（mm）	82	240/300
Max Illumination:1m(lx)	20000(±5%）	50000
Max Illumination:0.5m(lx)	60000	45000
Color - Rendering Index CRI（Ra）	95	95
Illuminance adjustment range	200~20000（1m） 1000~60000 （0.5m）	10~100%(Stepless adjustment）/5000~50000
Color temperature	4000K(±200K)	3000/4000/5000（±500）/3800-5200K(±200K)
Light spot diameter	240mm(1m) 160mm(0.5m)	180(±5%）/180-320
Radioactivity Ee/Ec（MW/m²lux）	≤3.6	≤3.4/≤4.5
Radiation power（w/m2 ）	＜200	＜180/＜600
Life span	＞60000h	＞60000h
Voltage(( v )	220V/50Hz	220V/50Hz
Power (w)	10	13/24

---
